A 15 mm deep lightbox for posters with a smooth front panel and bright illumination. Custom sizes, frame colours and passe-partout colours are available to order.

The front panel is held in place by magnets. To change the poster, simply remove the panel, replace the poster and put the panel back. The lightbox is available in single- and double-sided versions.

Magnetic provides particularly bright illumination across the front surface. Compared with a conventional lightbox, the single-sided version is approximately 50% brighter and the double-sided version up to 2x brighter.

Standard sizes include A3-A0, B2 and B1. We also manufacture Magnetic lightboxes made to measure up to 1250 x 2450 mm. Custom orders can also be specified with a different frame colour and passe-partout colour.

Frame width: 30 mm
Body depth: 15 mm
Use: single- or double-sided
Surface illuminance: up to 11000 lx
Luminous efficacy: up to 160 lm/W
CRI: >85
LED lifetime: 50000+ hours
Protection rating: IP40
Operating temperature: -30 to +40 C
Colour temperature of stock models: 6500 K
Available to order: 5000 K, 4000 K or 3000 K

A3
Poster size: 297 x 420 mm
Visible area: 275 x 394 mm
Lightbox dimensions: 329 x 448 x 15 mm
Daily electricity consumption: 0.16 kWh
Power: 7 / 14 W, single- / double-sided
Weight: 2.0 / 2.0 kg, single- / double-sided

A2
Poster size: 420 x 594 mm
Visible area: 398 x 568 mm
Lightbox dimensions: 452 x 622 x 15 mm
Daily electricity consumption: 0.43 kWh
Power: 9 / 18 W, single- / double-sided
Weight: 3.5 / 4.0 kg, single- / double-sided

A1
Poster size: 594 x 841 mm
Visible area: 572 x 815 mm
Lightbox dimensions: 626 x 869 x 15 mm
Daily electricity consumption: 0.62 kWh
Power: 26 / 26 W, single- / double-sided
Weight: 7.0 / 8.0 kg, single- / double-sided

A0
Poster size: 841 x 1189 mm
Visible area: 819 x 1163 mm
Lightbox dimensions: 873 x 1217 x 15 mm
Daily electricity consumption: 0.86 kWh
Power: 36 / 36 W, single- / double-sided
Weight: 14.0 / 16.0 kg, single- / double-sided

B2
Poster size: 500 x 700 mm
Visible area: 478 x 674 mm
Lightbox dimensions: 532 x 728 x 15 mm
Daily electricity consumption: 0.5 kWh
Power: 21 / 21 W, single- / double-sided
Weight: 5.0 / 6.0 kg, single- / double-sided

B1
Poster size: 700 x 1000 mm
Visible area: 678 x 974 mm
Lightbox dimensions: 732 x 1028 x 15 mm
Daily electricity consumption: 0.72 kWh
Power: 30 / 30 W, single- / double-sided
Weight: 10.0 / 11.5 kg, single- / double-sided

Max 1250 x 2450 mm
Poster size: 1250 x 2450 mm
Visible area: 1228 x 2424 mm
Lightbox dimensions: 1282 x 2478 x 15 mm
Daily electricity consumption: 1.92 kWh
Power: 80 / 80 W, single- / double-sided
Weight: 42 / 48 kg, single- / double-sided

Weights are approximate and may vary by +/-0.5 kg.

The poster is printed on light-diffusing backlit film. To replace the poster, remove the magnetic front panel and place it back after fitting the new poster.
Material: matt or gloss backlit film
Printing: eco-solvent printing
NB! Prepare the artwork according to the artwork guide for the selected model.
